RG-RAP6260(G) is one of the wireless products fully developed by Ruijie Reyee. The device supports 802.3at PoE In power supply. With concurrent 2.4GHz and 5GHz, the AP supports dual-band dual-stream MIMO technology, providing 574Mbps at 2.4G, and 1201Mbps at 5G.
RG-RAP6260(G) supports Reyee Mesh, which allows users easily expand extra Wi-Fi in outdoor place. Less wiring, more relaxing.
RG-RAP6260(G) applies for IP68 protection on the outer shell design, which is suitable in the outdoor environment and voids the influence from the extreme condition. The device meets the demanding requirements, such as able to perform under ultra-cold and humid weather. This reduces the difficulty of installation and maintenance. RG-RAP6260(G) supports Power over Ethernet remote mode, which is highly suitable for many scenarios such as education, government, medical, finance, business.
250₾–დან
10% OFF კუპონი: PC.GE
0.00₾
სტანდარტული მიწოდება თბილისში
სწრაფი მიწოდება თბილისში
10 ₾
სტანდარტული მიწოდება რეგიონებში
4-5 სამუშაო დღე
10 ₾
გარანტია 1 წელი
დეტალურად
დაბრუნების პოლიტიკა
დეტალურად
Payment Methods:
|
Technical Specification |
Specification Description |
|---|---|
|
Model |
RG-RAP6260(G) |
|
Radio |
Dual-stream dual-band |
|
Protocol |
Concurrent 802.11a/b/g/n/ac/ax |
|
Operating Bands |
802.11b/g/n/ac/ax ：2.4G ~ 2.4835GHz 802.11a/n/ac/ax： 5G：5.150～5.350GHz，5.725～5. (country specific) |
|
Antenna |
Internal antennas (2.4GHz: 4dBi，5GHz: 6dBi) |
|
Spatial Streams |
2.4 GHz 2×2 MU-MIMO 5 GHz 2×2 MU-MIMO |
|
Max Throughput |
Up to 574Mbps at 2.4GHz Up to 1201Mbps at 5GHz Totally 1775Mbps per AP |
|
Modulation |
DBPSK/DQPSK/CCK(DSSS)/BPSK/QPSK/16QAM/64QAM/256QAM/1024QAM |
|
Receive Sensitivity |
11b：-91dBm(1Mbps)，-88dBm(5Mbps)，-85dBm(11Mbps) 11a/g：-89dBm（6Mbps），-80dBm（24Mbps），-76dBm（36Mbps），-71dBm（54Mbps） 11n：-83dBm@MCS0，-65dBm@MCS7，-83dBm@MCS8，-65dBm@MCS15 11ac HT20：-83dBm（MCS0）, -57dBm（MCS9） 11ac HT40：-79dBm（MCS0）, -57dBm（MCS9） 11ac HT80：-76dBm（MCS0）, -51dBm（MCS9） 11ax：HE80：-82dBm（MCS0）, -57dBm（MCS9）,-52dBm（MCS11） |
|
Maximum Output Power of the Transmitter (Single Stream) |
2.4GHz(2.4~2.4835GHz)：26dBm 5GHz(5.150~5.250GHz,5.725~5.850GHz)：25dBm （country-specific，comply with local laws） |
|
Adjustable Power |
1dBm |
|
Dimensions |
298mm×298mm×65mm (excluding mounting kits) |
|
Weight |
≤1.35kg (excluding mounting kits) |
|
Service Ports |
1 10/100/1000 Base-T Ethernet port supports PoE IN； 1 100/1000 Base-X SFP Port |
|
Management Port |
N/A |
|
LED Indicator |
Single indicator (Blue light) |
|
Power Supply |
802.3at PoE (Warning：802.3af or non-standard POE adapter may cause unknown issues. Please use Ruijie POE+ switch or 802.3at POE adapter as power supplier) |
|
Power Consumption |
≤17W |
|
Bluetooth |
Support |
|
Environment |
Operating Temperature：-40°C～65°C |
|
Storage Temperature：-40°C～85°C |
|
|
Operating humidity：0%～100%, non-condensing |
|
|
Storage humidity：0%～100%，condensing/non-condensing |
|
|
Installation |
Pole/Wall-Mountable |
|
Safety Standard |
GB4943、IEC 60950-1 |
|
EMC Standard |
GB9254、EN301 489，EN50155：EN50121 |
|
Vibration Standard |
IEC61373 |
|
Radio Standard |
EN300 328，EN301 893 |
|
MTBF |
>400000H |
|
WLAN |
Maximum number of clients: 512 |
|
Recommended number of clients: 100 |
|
|
Up to 8 SSID |
|
|
Support SSID hiding Configuring the authentication mode, encryption mechanism, and VLAN attributes for each SSID |
|
|
SSID-based and radio-based STA limit |
|
|
Support Layer 2 user isolation |
|
|
Support Reyee Mesh |
|
|
Roaming |
Support layer 2 and layer 3 roaming |
|
Security |
Support PSK authentication |
|
Support static blacklist and whitelist |
|
|
Support WPA（TKIP）,WPA2（AES）,WPA-PSK data encryption |
|
|
Routing |
Support static IP address, DHCP, PPPoE Dial |
|
Management and Maintenance |
Support unified networking of all network equipment Support local or remote management with Ruijie Cloud APP Support local management with web Support remote management with Ruijie Noc Cloud platform |
|
Platform Management Features |
Automatic RF adjustment via the platform |
|
Unified configuration via the platform |
|
|
Unified monitoring via the platform |
