| General |
|
| Manufacturer |
HiWatch |
Other products |
| Model |
DS-I456Z(B)(2.8-12mm) |
|
| Type |
IP |
Other products |
| Frame |
Cylindrical |
|
| Purpose |
Street |
Other products |
| Camera |
|
| Max. permission |
4MP |
Other products |
| Matrix |
1/3″ Progressive Scan CMOS |
|
| Lens type |
Motorized / Varifocal |
|
| Lens |
Varifocal motorized lens from 2.8 to 12 mm |
|
| Viewing angle |
From 2.8 to 12 mm: horizontal from 102 to 31°, vertical from 55 to 18°, diagonal from 122 to 36° |
|
| Lens mount |
Ø 14 |
|
| Sensitivity |
Color: 0.005 lux @ (F1.6, AGC on); B/W: 0 lux with IR illumination |
|
| Backlight range |
up to 50m |
Other products |
| Recording |
|
| Main stream |
50Hz: 20fps (2560×1440), 25fps (2304×1296, 1920×1080, 1280×720) 60Hz: 20fps (2560×1440), 30fps (2304×1296, 1920×1080, 1280×720) |
|
| Additional stream |
50Hz: 25fps (1280×720, 640×480, 640×360) 60Hz: 30fps (1280×720, 640×480, 640×360) |
|
| Compression |
|
| Video compression |
H.264 / H.264+ / H.265 / H.265+ |
|
| Video bitrate |
From 32 Kbps to 8 Mbps |
|
| Net |
|
| Protocol |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP™, SMTP, IGMP, 802.1X, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS |
|
| Main |
|
| Nutrition |
DC 12V |
|
| Nutrition |
DC 12V ±25%, 0.9A, max 11W, coaxial power connector Ø 5.5mm PoE: (802.3af, class 3, 36 to 57V), 0.23 to 0.36A, max 12.9W |
|
| Protection class |
IP67 |
|
| Power consumption |
max 12.9 W |
|
| Working conditions |
From -40 to +60 °C. Humidity 95% or less (non-condensing) |
|
| Size |
Ø 105 × 244.4 mm (4.1 × 9.6″) |
|
| Weight |
Approx. 1035g |
