POE-24-AF5X

Output Voltage: 24VDC @1.0A

Input Voltage: 90-260VAC @47-63Hz

Input Current: 0.3A @120VAC, 0.2A @230VAC

Inrush Current: <15A peak @120VAC, <30A peak

Efficiency: 70+%

Output Ripple: 1% Max

Switching Frequency: 200kHz

Line Regulation: +/- 0.5%

Load Regulation : +/- 1%

Operating Temperature: -10C to +60 deg C

Storage Temperature: -20 to +85 deg C

Operating Humidity: -10C to +60 deg C

Size (LXWXH): 85 x 55 x 33 (mm)

AC Connector: IEC-320 C6

Data IN / POE: RJ45 Shielded Socket

80% Current Indicator: Power LED will change color

Surge Protection: Common Mode

Clamping Protection: 11V Data, 77.5V Power

Max Surge Discharge: 1200A (8/20uS) Power

Peak Pulse Current: 36A (10/1000uS Data)

Shunt Capacitance: <5pF data

Response Time: <1nS

Compliance: UL, EN55022 (CISPR22) class B, Meets CE
